IFM FLOW SENSOR SM6001 MAG INDUC 0.03>6.6-GPM, 18>30VDC ½”NPT TESTED! - $200 (LAKEWOOD)
11723 DEL AMO BLVD. near 605 FREEWAY
QR Code Link to This Post
Product characteristics
Outputs / Inputs
Number of digital outputs: 2
Number of analogue outputs: 1
Inputs: counter reset
Measuring range 1.5...396 gph 0.03...6.6 gpm
Process connection threaded connection G 1/2 external thread DN15 flat seal
Application
Special feature Gold-plated contacts
Application totaliser function; for industrial applications
Media conductive liquids; water; hydrous media
Note on media conductivity: ≥ 20 μS/cm
viscosity: < 70 mm²/s (40 °C)
Medium temperature: [°F] 14...158
Pressure rating: 16 bar 232 psi 1.6 MPa
MAWP for applications according to CRN:
15.3 bar 1.53 MPa
Electrical data:
Operating voltage [V] 18...30 DC; (to SELV/PELV)
Current consumption [mA] 95; (24 V)
Min. insulation resistance [MΩ] 100; (500 V DC)
Protection class III
Reverse polarity protection yes
Power-on delay time [s] 5
Measuring principle magnetic-inductive
PLEASE LOOK AT MY OTHER LISTED ITEMS, THEY MAY INTEREST YOU!!!
Everything that can be sanitized is wiped down and cleaned.
This item is from a smoke / vape free location.
You can be confident that my description of this item is honest and forthcoming.
If you have any questions regarding this item, please contact me.
