SM-652 Solar/Wind 48VDC Inverter Split Style Air Conditioner/Heat Pump - $1,195 (El Monte)
Garvey Ave near Central Ave
condition:
new
make / manufacturer:
Go! Solar!
model name / number:
SM-652
size / dimensions:
36″x 25″ x 16″
QR Code Link to This Post
1. SM-652 Solar Air Conditioner – Mini Split Style 48VDC for connection to
1)Existing Solar System’s 48V battery bank
2)Connecting to a 48VDC MPPT Controller + 3 x 455W Solar Panels(9000/12000BTU) – 4 for 18000BTU
Or a Wind/Solar 2000W Hybrid MPPT Controller + Solar Panels & 1500W Vertical Axial Wind Turbine
3) Please click the link to read the spec sheet: DC48V specification
https://symmetryco.com/wp-content/uploads/2021/04/SM-652-Off-Grid-48VDC-Solar-AC-SPEC.pdf
4) Please click the link to read the Instruction Manual: Solar Aircon DC48V Installation And Operation Manual
https://symmetryco.com/wp-content/uploads/2021/04/Solar-Aircon-DC48V-Installation-And-Operation-Manual-.pdf
5) General Spec:
Capacity Solar Panels ODU Dimension Weight IDU Dimension Weight
————————————————————————————————————————————––
9000 BTU 1200W 36″x 25″ x 16″ 71 lbs 36″x 11″x 14″ 28 lbs
12000 BTU 1200W 36″x 25″ x 16″ 79 lbs 36″x 11″x 14″ 28 lbs
18000 BTU 1600W 36″x 25″ x 16″ 92 lbs 45″x 12″x 15″ 38 lbs
Lineset:
======
The unit comes with a 10 ft Lineset but we have SM-650-10 & SM-650-17 extension lineset for sales,
so buyers can extend the distance from 10ft to 10ft+10ft = 20ft or 10ft+17ft = 27ft etc.
Additional SM-650-10: (1/4"x0.7 + 3/8" x 0.7) x 10 ft Extension Lineset $59.99
and SM-650-17:(1/4" x 0.7 + 3/8" x 0.7) x 16.5 ft Extension Lineset $89.99
Coolant R410a:
==============
New law required manufacturers preloaded the coolant, so buyers only needed to vacuum the passage in between indoor and outdoor units.
2.Federal Income Tax 30% Credit for Residential Solar System & Equipment:
=============================================================
In "the Inflation Reduction Act of 2022", the tax credit will begin at 30% and step down to 26% in 2033 and 22% in 2034.
****Very sorry to inform everybody, after the BIG AND BEAUTIFUL act, the great 30% Residential Solar rebate had been cancelled.
The last available project will be by the end of 2025, so if you are considering, ACT Now!
****Download form from this link and give to your accountant
https://www.irs.gov/pub/irs-pdf/f5695.pdf
2022~2032: 30%
2033: 26%
2034: 22%
New Features:
Included Storage Investment, either combine with solar or separately
Tax Credit Deduction can be extended to Next year if the first year tax amount is lower than credit.
During Day times, you get free energy to blow cooling air to your space.
At nights, machine can automatically be switched to battery storage or Grid Power, if any!
If you do not have budget for solar, install the Solar Air conditioner first and next month
adding the solar system or next year. When you have more budget to get the power system.
However Solar pays itself back in no time! Considering half of your utility bill pays for Air Conditioners in Summers!
So you are not actually spending money, just the electric bill saving. Already enough to pay for this Solar Air conditioner.
3. Refrigerant R32 – please ask your installer to vacuum the passage during installation.
4. Shipping: Flat Rate Shipping $400 per Indoor/Outdoor Unit Pair – only to lower 48 states only!
5. For local purchasing & Delivery:
==========================
Please come to our El Monte Store to pick up
or use uBer Connect for same day delivery!
**It's cheaper than passenger fares, because the drivers can deliver the packages
when in your area and no need to chat/entertain the "passenger"! :-)
Customers who have an uBer account can get an estimate by using the pickup location : 91733
Pickup at El Monte or purchase online, thank you!
https://symmetryco.com/product/sm-652-48vdc-inverter-ac/
