9 inch & 8 inch Ford rear ends, Posis, Parts & Brakes - $100 (Downey)
QR Code Link to This Post
9 inch rear end 1964 1/2 to 1965 Mustang, drum to drum, 57 3/8 wheel to wheel, Rebuilt 28 spline posi 3rd member, Narrowed downed tubes like 289 K Code and Shelbys, 3:50 Gears, 43" spring flange to flange and 57 1/2 wheel to wheel, will fit 67-68 and 71-73 Mustangs $2,100.00 ......31 Spline extra...
9 inch rear end 1975 to 1980 Granada will fit in 1965-66 Mustang, drum to drum, Very strong center housing section, 3" tubes, 58 wheel to wheel, 3:00 Gears, 43" spring flange to flange and 58 wheel to wheel, will fit 67-68 and 71-73 Mustangs $9,50.00 ......31 Spline and or Posi extra...
9 inch 1971-1973 drum to drum, rare, fits 71-73 Mustang and Cougar, 43" spring flange to flange and 61 1/2 wheel to wheel, will fit 65-66 and 67-70 Mustangs, lug pattern is 5x4.5, axles are 28 spline, 2:75 open (other gear ratios available), $950.00... posi 3:50 or 31 Spline extra...
9 inch 1970-1971 Torino Station Wagon and Ranchero, drum to drum, rare, also fits 70-71 Torino & 71-73 Mustang and Cougar by changing pads,, 43" spring flange to flange and 61 1/2 wheel to wheel, will fit 65-66 and 67-70 Mustangs but wider if needed, , lug pattern is 5x4.5, axles are 28 spline, 2:75 open (other gear ratios available), $950.00... posi 3:50 or 31 Spline extra...
9 inch 1967-70 drum to drum, rare, fits 67-70 Mustang and Cougar, 43" spring flange to flange and 59 1/2 wheel to wheel, will fit 65-66 and 71-73 Mustangs, lug pattern is 5x4.5, axles are 28 spline, 3:00 open (other gear ratios available), $950.00... with posi 3:25 or other posis extra...
8 inch 1967-70 drum to drum, rare, fits 67-70 Mustang and Cougar, 43" spring flange to flange and 59 1/2 wheel to wheel, will fit 65-66 and 71-73 Mustangs, lug pattern is 5x4.5, axles are 28 spline, 3:00 open (other gear ratios available), $495.00... posi 3:50 or other ratio extra...
8 Inch 1980 Granada , drum to drum, 5 Lug, open 3:00 3rd member, fits 65-66 Mustang, 43" spring flange to flange and 57 5/8 wheel to wheel, will also fit 67-68 and 71-73 Mustangs and will shorten the width to run bigger tires, $550.00
8 Inch 1970-73 Maverick, drum to drum, 5 Lug, axles short side 25 5/8 and long side 29 5/8, open 3:00 3rd member, fits 65-66 Mustang, 43" spring flange to flange and 56 3/4 wheel to wheel, one of the narrowest Ford rear ends made, will also fit 67-68 and 71-73 Mustangs and will shorten the width to run bigger tires, $750.00 Sold
8 Inch1963 Fairlane/Falcon , All mew brakes and drums and springs and wheel cylindersone year only, extremely rare, drum to drum, 5 Lug, open 3:00 3rd member, fits 65-66 Mustang, 43" spring flange to flange and 56 3/4 wheel to wheel, one of the narrowest Ford rear ends made, will also fit 67-68 and 71-73 Mustangs and will shorten the width to run bigger tires, $1450.00 Sold
8 inch rear end 1964 1/2 to 1965 Mustang, drum to drum, 57 3/8 wheel to wheel, 3.00 3rd member, factory Narrowed downed tubes, 43" spring flange to flange and 57 1/2 wheel to wheel, will also fit 67-68 and 71-73 Mustangs $750.00 ......
9 inch big bearing big bearing housings bare, different lengths $275.00 each
1971-1973 9 inch housing, rare, fits 71-73 Mustang and Cougar, 43" spring flange to flange, small bearing 56" width..$300.00
1967 Van Housing with wide backing plates, large fill plug in the back... $475.00
9 Inch 57 Ford Early Housing 52' $275.00
9 inch big bearing 1980 Granada housing, factory reinforced and stronger than regular 9 inch housing, 52 1/2, bare, rare, like 65-66 Mustang but 1/2 wider, 58 inches axle face to axle face, $400.00 with 10 X 2 1/2 backing plates $200.00 extra 28 & 31 spline axles new or used available also Sold
9 inch big bearing & small bearing housings bare, different lengths $275.00 each
9 inch 31 New Currie 31 and 28 Spline Track Lock 4 pinion l, Posi, only posi..$375.00.......
9 inch 31 Spline Track Lock 4 pinion later stronger case Posi, only posi..$175.00.......
9 inch 28 Spline Posi 3rd member, 3:25 gear ratio, with yoke, used, $475.00
9 inch 28 Spline Posi 3rd member, 3:70 gear ratio, with yoke, used, $525.00 Sold
9 inch 28 Spline Open 3rd member, 3:25 gear ratio, with yoke, used, $275.00
9 inch 28 Spline Posi 3rd member, 3:25 gear ratio, Detroit locker with yoke, used, $625.00
9 inch 28 Spline Open 3rd member, 2:75 gear ratio, with yoke, used, $275.00
9 inch 5.14 Spool Posi 31 Spline 3rd member, Nodular case $975. .......
9 inch 4.57 Detroit Locker Posi 31 Spline 3rd member, Nodular case with December 1968 date, driver Cap is aftermarket, stock front retainer, Yoke needs to be put on, $700.00 .......
9 inch 4.57 Detroit Locker Posi 31 Spline 3rd member, $6500.00 .......
9 inch 4.11 31 Spline 3rd member, Track Lock 4 pinion later stronger case Posi, $750.00......
9 inch 4.11 31 Spline 3rd member, Detroit Locker Posi, $750.00....... Sold
9 inch 4.11 31 Spline 3rd member, Spool Posi, $450.00.......
9 inch 31 Spline Posi Detroit Locker, Daytona retainer, small bearing, Nodular Case, 3.70 gear ratio, with yoke, used, $1050.00
9 inch 31 Spline Posi 3rd member, 3.50 gear ratio, with yoke, has alternator pulley too, used, $550.00
9 inch 31 Spline Open 3rd member, 3.50 gear ratio, with yoke, used, $275.00
9 inch 31 Spline Posi 3rd member, Airlocker 3.25 gear ratio, with yoke, used, $550.00
9 inch 31 Spline Posi 3rd member, 3.25 gear ratio, with yoke, used, $475.00
9 inch 31 Spline Posi Detroit Locker, Daytona retainer, small bearing, Nodular Case, 3.50 gear ratio, with yoke, used, $1050.00
9 inch 31 Spline 3rd member, Posi with broken case, 3.50 gear ratio, with yoke, used, $390.00
Ford 9 inch 3.50 31 Spline 3rd member 4 pinion Trac Loc posi Traction Febuary 14th 1969 date code, Correct for 428Cj,SCJ, Boss 302 and other cars $1400.00.......
9 Inch 31 Spline Traction Loc Posi, New Curry not Chinese , 4 Pinion, Billet side cover $350.00
9 inch 31 Spline Traction Loc Curry Posi Traction 4 Pinion 3rd member, 3:50 gear ratio, with yoke, refurbished $750.00 rebuilt (all new bearings and new clutches) not Chinese parts $1050.00 ......
9 inch 31 Spline open 3rd member, 2.75 gear ratio, with yoke, used, $275.00
9 inch 31 Spline open 3rd member, 3:25 gear ratio, with yoke, used, $275.00
9 inch 31 Spline Posi 3rd member, 3:25 gear ratio, with yoke, used, $475.00
9 inch 31 Spline open 3rd member, 3:25 gear ratio, with yoke, used, $275.00
9 inch pinion snubber bracket and rubber, made like 65-66 289 HP, cleaned and painted, $150.00
9 inch pinion snubber bracket and rubber, made like 67 up 390, cleaned and painted, $150.00
9 inch 4:57 Ring and Pinion, good used set $125.00
9 inch 4:56 Ring and Pinion, good used set $125.00
9 inch 4:11 Ring and Pinion, good used set $125.00
9 inch 3:50 Ring and Pinion, good used set $150.00
9 inch 3:70 Ring and Pinion, good used set $125.00
9 inch 2:80 Ring and Pinion, good used set $120.00
9 inch axles 28 spline, 27 1/8" & 31 1/8" 1 pair with bearings and retainer plates $175.00
9 inch axles 28 spline, 28 1/8" & 32 1/8" 1 pair with bearings and retainer plates $175.00
9 inch large Mustang, Torino, Fairlane yoke $95.00
11" X 1 3/4" Rare small bearing backing plates and drums and hardware, used, small bearing $150.00
10" X 1 3/4" small bearing backing plates and drums and hardware, used, small bearing $150.00
10" X 2" small bearing backing plates and drums and hardware, used, small bearing $200.00
10 X 2 1/2 small bearing wide rear end rear drum brakes, backing plates fully loaded with crossover bar and emergency arm and hardware, small bearing, 1 pair, very rare, same dimensions as came with Shelbys, these are correct backing plates for early Shelbys with Ford correct drums, more stopping power than many rear disc set ups, used $750.00
Shelby factory ultra rare 10 X 2 1/2 drums $ 800.00 to 1200 a pair depending on condition
10" X 2 1/2 big bearing backing plates and drums and hardware, used, small bearing $400.00
8 inch yoke early Mustang & others $50.00
8 Inch 3:25 ring and pinion $125.00
8 inch posi 3rd member, 3:40 gears, good condition, ready to drop in $700.00 Sold
And more
Jim
five-six-two-eight-o-seven-four-two-eight-six
(this does not get caller ID so leave a phone number, and leave the number clearly twice at the beginning of the message as many times the cell phones reception is not clean for leaving a message)
jpwarino at y a hoo dot com
visit the following web address for many car albums full of pictures: http://s1117.photobucket.com/albums/k600/megazone1/
Key Words: Ford, Lincoln, Mercury, Cougar , Fairlane, Mustang, 1965, 1966, 1967, 1968, 1969, 1970, Torino, Galaxie, GTA, Meteor, Comet, Falcon, high Performance, Shelby, Holman and Moody, Buddy Barr, GT, 289, 302, 427, 428, 390, 351, cruiser, show car, daily driver, restoration, Mach 1, clean,
